Storefront Framing

Trifab® VersaGlaze® 451/451T Framing System

Trifab® VersaGlaze® Framing system is built on the proven and successful Trifab® framing platform – with all the versatility its name implies. Designed for performance and unmatched fabrication flexibility, the Trifab® VersaGlaze® Framing System can be used on almost any project. Trifab® VersaGlaze® Framing system also offers pre-glaze option for the existing center set screw spline assembly application, available on non-thermal, thermal and ultra-thermal frame types. Pre-glaze units can be completely fabricated and glazed in the shop, minimizing job-site costs and enhancing field-installed quality.

  • 2″ (50.8mm) sightline
  • 4-1/2″ (114.3mm) depth
  • High-thermal performance
  • Front, center, back or multi-plane glass applications
  • Blast mitigation (451T), hurricane resistance
  • Structural silicone glazed (SSG) options, pre-glazed options
  • Test
  • Hurricane impact tested on shutter application only
  • 4-1/2″ (114.3) deep with a 2″ (50.8) sightline
  • Front, center, back or multi-plane glass applications
  • Flush glazed from either the inside or outside
  • Screw spline, shear block, stick or type-B fabrication
  • Screw spline pre-glaze option
  • SSG / weather seal option
  • Isolock® lanced and debridged thermal break option
  • Infill options up to 1-1/8″ (28.6) thickness
  • Anodized finishes in four choices
  • Painted finishes in standard and custom choices

Optional Features

  • Acoustical rating per AAMA 1801 and ASTM E 1425
  • Project specific U-factors (see Thermal Charts in Architectural Detail Manual)
  • Profit$Maker® plus die sets available

Pre-glaze option features*

  • Tested solution with installation instructions enables shop fabrication and reduces field labor
  • Vertical mullions with 1/4″ reveal provide uniform aesthetics
  • High-performance sill flashing and clip design reduce installation time
  • Composite end jamb allows for ease of installation of the last bay
  • Trifab® 451/451T/451UT Framing Systems provide the right thermal performance for your project
  • View our pre-glaze option flyer here

*For Trifab® 451/451T/451UT Framing System center set screw spline assembly applications only

Product Applications

  • Storefront, ribbon window or punched openings
  • Single span
  • Integrated entrance framing allowing Kawneer standard entrances or other specialty entrances to be incorporated
  • Kawneer windows are easily incorporated

Thermal Technology

Find out more here.

Blast Resistant

Find out more here.

Hurricane Resistant

Find out more here.
